EMC Isilon Frontend Automation API

The Isilon Manager API provides fully automated SMB/NFS storage provisioning for DellEMC Isilon NAS solutions. When installed between customer and the Isilon management interfaces, the API expects to receive validated JSON input from an external resource, such as a webform, command-line curl or VMware VRA/VRO. Based on this input, it will create the full /ifs-path framework, the SMB-share or NFS-export including permissions, configure ACLs, the replication-policy with email notification,  and SmartQuota’s. Optionally, it will also create the SmartLock Enterprise/Compliance domain with the requested retentions.

SMB and NFS compatible

Create SMB shares or NFS exports complete with permissions & ACL’s

SyncIQ Replications

Setup SyncIQ replication policies with default settings

SmartQuota Notifications

Configure a custom hard or advisory quota on each resource.

SmartLock

Create optional WORM domain in Enterprise or Compliance SEC17A4 Mode

How does it work?

AThe Isilon Manager API provides fully automated SMB/NFS storage provisioning for DellEMC Isilon NAS solutions. When installed between end-user and the Isilon management interfaces, the API expects to receive validated JSON input from an external resource, such as a webform, command-line curl or VMware VRA/VRO. Based on this input, it will work with the builtin Isilon API to create the full /ifs-path framework, the SMB-share or NFS-export including permissions, configure ACLs, the replication-policy with email notification,  and SmartQuota’s. Optionally, it will also create the SmartLock Enterprise/Compliance domain with the requested retentions.

System Requirements with on-site Installation Service

  • Linux compatible OS (RedHat/Centos)
  • Apache Tomcat 8+
  • Java JDK/JRE 1.8+

Features

  • OneFS 8.0.0.5 / 8.1.0.x compatible
  • NFSv3 / NFSv4 compatible
  •  Create SMB share or NFS export, in correct Access Zone
  • SMB share and NFS export – set description to owner & department
  • SMB share – validate & set permissions using Active Directory Groups
  • SMB share – set ACLs using Active Directory Groups on full /ifs-path
  • NFS export – set host permissions on NFS export after host validation
  • NFS export – set permissions on /ifs-path (set to root or compadmin)
  • SmartLock – set WORM minimum, default, and maximum-retentions
  • SyncIQ – create Replication Policy for non-SmartLock on server-level
  • SyncIQ – create Replication Policy for SmartLock on full /ifs-path
  • SmartQuota – set Hard Quota & Advisory Quota, and email notifications
  • SmartQuota – prevent Isilon cluster overcommitting
